Toshiba TOSVERT VF-nC3E - Page 214

E6582233
J-7
10
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F292 0292 Preset-speed
frequency 13
Hz 0.1/0.01

0.0 3.5
6.11

F293 0293 Preset-speed
frequency 14
Hz 0.1/0.01

0.0

F294 0294
Preset-speed
frequency 15
Hz 0.1/0.01

0.0
 Operation mode parameters
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F300 0300 PWM carrier
frequency
kHz 1/0.1 2 -12 (Over 4kHz is available at
f316=0,1)
4 6.12

F301 0301 Auto-restart
control selection
- - 0: Disabled
1: At auto-restart after momentary
stop
2: At ST terminal off and on
3: 1+2
4: At start-up
0 6.13.1

F302 0302 Regenerative
power ride-
through control
(Deceleration
stop)
- - 0: Disabled
1: Regenerative power ride-through
control
2: Deceleration stop during power
failure
0 6.13.2

F303 0303 Retry selection
(number of times)
Time
s
1/1 0: Disabled
1-10
0 6.13.3

F304 0304 Dynamic braking
selection
- - 0: Disabled
1: Enabled, Resistor overload
protection enabled
2: Enabled
3: Enabled, Resistor overload
protection enabled
(At ST terminal on)
4: Enabled (At ST terminal on)
0 6.13.4

F305 0305 Overvoltage limit
operation
(Slowdown stop
mode selection)
- - 0: Enabled
1: Disabled
2: Enabled (Quick deceleration
control)
3: Enabled (Dynamic quick
deceleration control)
2 6.13.5

F307 0307 Supply voltage
correction
(output voltage
limitation)
- - 0: Supply voltage uncorrected,
output voltage limited
2 6.13.6
1: Supply voltage corrected,
output voltage limited
2: Supply voltage uncorrected,
output voltage unlimited
3: Supply voltage corrected,
output voltage unlimited

F308 0308 Dynamic braking
resistance
Ω 0.1/0.1 1.0-1000 *1 6.13.4

F309 0309 Dynamic braking
resistor capacity
kW 0.01/0.01 0.01-30.00 *1

F310 0310 Factory specific
coefficient 3A
- - - -
* 2
*1: Default setting values vary depending on the capacity. Refer to section 10.4.
*2: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
