E6582233
J-3
10
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference
OLM 0017 Electronic-thermal
protection
characteristic
selection
- -
Setting Overload protection OL stall
0 3.4
0
Standard
motor
valid invalid
1 valid valid
2 invalid invalid
3 invalid valid
4
VF motor
valid invalid
5 valid valid
6 invalid invalid
7 invalid valid
SR1 0018 Preset-speed
frequency 1
Hz 0.1/0.01 - 0.0 3.5
SR2 0019 Preset-speed
frequency 2
Hz 0.1/0.01 - 0.0
SR3 0020 Preset-speed
frequency 3
Hz 0.1/0.01 - 0.0
SR4 0021 Preset-speed
frequency 4
Hz 0.1/0.01 - 0.0
SR5 0022 Preset-speed
frequency 5
Hz 0.1/0.01 - 0.0
SR6 0023 Preset-speed
frequency 6
Hz 0.1/0.01 - 0.0
SR7 0024 Preset-speed
frequency 7
Hz 0.1/0.01 - 0.0
TYP 0007 Default setting - - 0: -
1: 50Hz default setting
2: 60Hz default setting
3: Default setting 1 (Initialization)
4: Trip record clear
5: Cumulative operation time clear
6: Initialization of type information
7: Save user setting parameters
8. Load user setting parameters
9. Cumulative fan operation time
record clears
10 to 11: -
12: Number of starting clear
0 4.3
4.3.2
PSEL 0050 Registered
parameters display
selection
- - 0: Standard setting mode at power on
1: Easy setting mode at power on
2: Easy setting mode only
0 4.4
F1-- -
Extended parameter
starting at 100
- - - - - 4.2.2
F2-- -
Extended parame
er
starting at 200
--- --
F3-- -
Extended parameter
starting at 300
- - - - -
F4-- -
Extended parameter
starting at 400
- - - - -
F5-- -
Extended parameter
starting at 500
--- --
F6-- -
Extended parameter
starting at 600
- - - - -
F7-- -
Extended parameter
starting at 700
- - - - -
F8-- -
Extended parameter
starting at 800
--- --
GRU - Automatic edit
function
- - - - - 4.3.1
