E6582233
J-2
10
Ti tle
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

FMSL 0005 Meter selection - - 0: Output frequency
1: Output current
2: Frequency reference
3: Input voltage (DC detection)
4: Output voltage (command value)
5 to 11: -
12: Frequency setting value (after
compensation)
13: VI input value
14: -
15: Fixed output 1
(output current 100% equivalent)
16: Fixed output 2
(output current 50% equivalent)
17: Fixed output 3
(Other than the output current)
18: RS485 communication data
19: For adjustments ( set value is
displayed.)
20 to 22: -
0 3.3

FM 0006 Meter adjustment
gain
- - - -

FR 0008 Forward/reverse
run selection
(Panel keypad)
- - 0: Forward run
1: Reverse run
2: Forward run (F/R switching on
extension panel)
3: Reverse run (F/R switching on
extension panel)
0 5.7

ACC 0009 Acceleration time
1
S 0.1/0.1 0.0-3000 10.0 5.3

DEC 0010 Deceleration time
1
S 0.1/0.1 0.0-3000 10.0

FH 0011 Maximum
frequency
Hz 0.1/0.01 30.0-400.0
50
5.8

UL 0012 Upper limit
frequency
Hz 0.1/0.01 0.5- 
50
5.9

LL 0013 Lower limit
frequency
Hz 0.1/0.01 0.0-  0.0

VL 0014 Base frequency 1 Hz 0.1/0.01 20.0-400.0
50
5.10

VLV 0409 Base frequency
voltage 1
V 1/0.1 50-660
400
5.10
6.13.6

PT 0015 V/F control mode
selection
- - 0: V/F constant
1: Variable torque
2: Automatic torque boost control
3: Vector control
4: Energy-saving
5 to 6: -
7: V/F 5 point setting
0 5.11

VB 0016 Torque boost
value 1
% 0.1/0.1 0.0-30.0 * 1 5.12

THR 0600 Motor electronic-
thermal protection
level 1
%
(A)
1/1 10-100 100 3.4
6.18.1
*1: Default setting values vary depending on the capacity. Refer to section 10.4.
