E6582233
A-8
1
(3) Removing the power terminal cover (VFNC3E-4075P, 4110P)
★ After wiring is complete, be sure to restore the terminal cover to its original position.
1)
2)
3)
4)
Insert a screwdriver or other thin object into the
hole indicated with the
mark.
Press the screwdriver.
While pressing on the screwdriver, pull the
terminal cover downward to remove it.
Pull up the wire trapping cover upward to
remove it.
To Next Page
