Communication parameters
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference
F800 0800
Baud rate - - 3: 9600bps
4: 19200bps
5: 38400bps
4 6.21
F801 0801
Parity - - 0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
1
F802 0802
Inverter number - 1/1 0-247 0
F803 0803
Communication
time-out time
s 0.1/0.1 0.0: Disabled,
0.1-100.0
0.0
F804 0804
Communication
time-out action
- - 0: Alarm only
1: Trip (Coast stop)
2: Trip (Deceleration stop)
0
F808 0808
Communication
time-out detection
condition
- - 0: Valid at any time
1: Communication selection of
fmod or cmod
2: 1 + during operation
1
F829 0829
Selection of
communication
protocol
- - 0: Toshiba inverter protocol
1: Modbus RTU protocol
0
F870 0870
Block write data 1 - - 0: No selection
1: Command information
2: -
3: Frequency command value
4: Output data on the terminal board
5: Analog output for communication
0
F871 0871
Block write data 2 - - 0
F875 0875
Block read data 1 - - 0: No selection
1: Status information
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal board monitor
8: Output terminal board monitor
9: VI terminal board monitor
0
F876 0876
Block read data 2 - - 0
F877 0877
Block read data 3 - - 0
F878 0878
Block read data 4 - - 0
F879 0879
Block read data 5 - - 0
F880 0880
Free notes - 1/1 0-65535 0 6.22
