E6582233
J-18
10
Table of input terminal functions 2
Function
No.
Code Function Action Reference
88 UP Frequency UP ON: Frequency increased
OFF: Frequency increase canceled
6.6.3
89 UPN Inversion of frequency UP Inversion of UP
90 DWN Frequency DOWN ON: Frequency decreased
OFF: Frequency decrease canceled
91 DWNN Inversion of frequency DOWN Inversion of DWN
92 CLR Clear frequency UP/DOWN
OFF → ON: Clear frequency UP/DOWN
93 CLRN Inversion of clear frequency UP/DOWN Inversion of CLR
96 FRR Coast stop command ON: Coast stop (Gate OFF)
OFF: Coast stop canceled
3.1.1
97 FRRN Inversion of coast stop command Inversion of FRR
106 FMTB Frequency setting mode terminal board VI ON: Terminal board (VI) enabled
OFF: Setting of
5.5
107 FMTBN Inversion of frequency setting mode terminal
board VI
Inversion of FMTB
108 CMTB Command mode terminal board ON: Terminal board enabled
OFF: Setting of
109 CMTBN Inversion of command mode terminal board Inversion of CMTB
110 PWE Parameter editing permission ON: Parameter editing permitted
OFF: Setting of
6.20.1
111 PWEN Inversion of parameter editing permission Inversion of PWE
122 FST Forced deceleration command ON: Forced deceleration command (Automatic deceleration)
OFF: Forced deceleration canceled
(Note that operation is resumed when forced deceleration is
canceled)
5.3.1
123 FSTN Inversion of forced deceleration command Inversion of FST
200 PWP Parameter editing prohibition ON: Parameter editing prohibited
OFF: Setting of
6.20.1
201 PWPN Inversion of parameter editing prohibition Inversion of PWP
Note 1: Function No. 26, 27, 30, 31, 34, 35, 38 to 47, 50, 51, 56 to 87, 94, 95, 98 to 105, 112 to 121 and 124 to 199 are
assigned "No function".
