Configuration Procedure:
Step Operation Description
1
Set the link type for port. Required. On the VLAN→802.1Q VLAN→Port Config page,
set the link type for the port basing on its connected device.
2
Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config
page, click the Create button to create a VLAN. Ente
r the
VLAN ID and the description for the VLAN. Meanwhile,
specify its member ports.
3
Create VLAN interface. Required. On the Routing→Static Routing→Static Routing
Config page, create the interface IP address of the VLAN.
4
Enable DHCP Server. Required. On the Routing→DHCP Server→DHCP Server
page, enable the DHCP Server function.
5
Configure Excluded IP
Address.
Optional. On the Routing→DHCP Server→DHCP Server
page,
configure the Excluded IP Address which cannot be
assigned by the switch.
6
Configure IP Pool. Required. On the Routing→DHCP Server→Pool Setting
page,
configure the parameters of IP Pool, including Mask,
lease time, gateway and DNS address.
7
Bind IP Manually Optional. On the Routing→DHCP Server→Manual Binding
page, you can specify the IP address for specific clients.
10.4.6 Application Example for DHCP Server and Relay
 Network Requirements
 Every building in the campus belongs to separate VLANs with different network segments.
 The access points in each building are divided into two parts. One part is the fixed computers
with static IP addresses in the teachers’ offices; the other is the classroom, in which most
clients are laptops with dynamic IP addresses obtained from the DHCP server.
 DNS Server is in VLAN 1and its IP address is 160.20.30.2.
