TRENDnet TL2-G244 - 802.1 X Basic Settings; 802.1 X Port Settings

24-Port Gigabit Layer 2 Switch w/ 4 Shared Mini-GBIC Slots
6-18
802.1X
802.1X Basic Settings
This page is used to configure the 802.1X authentication global settings.
Figure 54 – Layer2 Management > 802.1X > Basic Settings
Parameter
Description
System Control
To activate or shutdown 802.1X function of the Switch. Select
Start
to activate
the function, Shutdown to shutdown it. Default is Start.
802.1X Authentication
To enable or disable the 802.1X authentication of the Switch. Select
Enabled
to enable the function, Disabled to disable it. Default is Disabled.
Authentication Mode
Select the authentication database for 802.1X.
Remote
is to use the RADIUS
server; Local will use the local database. Default is Local.
Network Access
Server ID
Specify the remote RADIUS server authenticator ID.
Protocol Version
Specify the protocol version of 802.1X.
Click Apply to submit the changes.
802.1X Port Settings
This page is to configure the port related setting of 802.1X.
Figure 55 – Layer2 Management > 802.1X > Port Settings
Parameter
Description
