MSTP
MSTP Information
This page is to display current MSTP settings and states of the Switch.
Figure 86 – Statistics > MSTP > MSTP Information
MSTP CIST Port Statistics
This page is to display the MSTP traffic statistics of ports.
Figure 87 – Statistics > MSTP > CIST Port Statistics
Parameter
Description
Clear Counters
Update
– To display the latest statistics information.
Clear – To reset all MSTP traffic counters.
Click Apply to update or clear the statistics of the Swtich.
Click 1-12, 13-24 to display the MSTP traffic statistics of corresponding ports.
MSTP MSTI Port Statistics
This page is to display the MSTP traffic statistics of different instances in each port.
Figure 88 – Statistics > MSTP > MSTI Port Statistics
