24-Port Gigabit Layer 2 Switch w/ 4 Shared Mini-GBIC Slots
10-12
RSTP
RSTP Information
This page is to display current RSTP setting and states of the Switch.
Figure 89 – Statistics > RSTP > RSTP Information
RSTP Port Statistics
This page is to display the RSTP traffic statistics of ports.
Figure 90 – Statistics > RSTP > Port Statistics
Parameter
Description
Clear Counters
Update
– To display the latest statistics information.
Clear – To reset all RSTP traffic counters.
Click Apply to update or clear the statistics of the Switch.
Click 1-12, 13-24 to display the Link Aggregation neighbours information of corresponding ports.
LA
LA Port Statistics
This page is to display the traffic statistics of Link Aggregation ports.
