24-Port Gigabit Layer 2 Switch w/ 4 Shared Mini-GBIC Slots
7-6
Figure 70 – ACL > Classmap
Specify the classmap ID. The possible value is 1-65535.
Specify the ACL rule ID to bind.
Specify the type of the ACL rule.
Click Add to create a new classmap, Reset to clear the value.
Select a classmap to delete
The ID of binding ACL rule.
The type of binding ACL rule.
Click Delete to delete selected classmap.
Policymap Settings
This page is to create/configure a policymap.
Figure 71 – ACL > Pokicymap
Specify the policymap ID. The possible value is 1-65535.
Specify which classmap to bind.
Set the traffic rate threshold in Kbps for the class map.
Specify the action to packets do not exceed the rate threshold. The options
