Figure 104 –Relationship of Command Modes
User EXEC Mode
When login the .Switch using privilege level 1 accounts, user will entering User
EXEC Mode automatically. User EXEC mode is used to do the basic operation
such as show commands.
Privileged EXEC
Mode
When login the .Switch using privilege level 15 accounts, user will entering
Privileged EXEC Mode automatically. A password is required to enable Privileged
EXEC Mode, default is password.
Global
Configuration
Mode
The Global Configuration Mode is used to configure the global commands which
will take effect to whole system and all interfaces.
Interface
The Interface Configuration Mode is used to configure the commands for physical
switch(config-vlan)#
Config-vlan Mode
switch(config)#
Global Configuration Mode
switch(config-if)#
Interface Configuration Mode
switch#
Privileged EXEC Mode
switch>
User EXEC Mode
enable
configure
terminal
interface
vlan
disable
exit
exit
exit
switch(config-mst)#
MSTP Configuration Mode
switch(config-ext-macl)#
MAC Access List
Configuration Mode
switch(config-std-nacl)#
Standard IP Access List
Configuration Mode
switch(config-EXT-nacl)#
Extended IP Access List
Configuration Mode
exit
spanning-tree mst
configuration
exit
mac access-list
extended
ip access-list extended
ip access-list standard
exit
exit
end
switch(config-cmap)#
Class-map Configuration Mode
switch(config-pmap)#
Policy-map Configuration Mode
switch(config-pmap-c)#
Policy-map Class Configuration
Mode
class-map
exit
exit
policy-map
class
exit
