210 CM Baseplate Connectors
Trident Planning and Installation Guide
9 Rx_Clk In Receive clock
10 Rx_Er In Receive error
11 Tx_Er Out Transmit error
12 Tx_Clk In Transmit clock
13 Tx_En Out Transmit enable
14 TxD<0> Out Transmit data 0
15 TxD<1> Out Transmit data 1
16 TxD<2> Out Transmit data 2
17 TxD<3> Out Transmit data 3
18 Col In Collision (half-duplex)
19 CRS In Carrier receive sense
20 +5 V Out MII MAU power
21 +5 V Out MII MAU power
22 Logic
ground
— MII MAU logic ground
23 Logic
ground
— MII MAU logic ground
24 Logic
ground
— MII MAU logic ground
25 Logic
ground
— MII MAU logic ground
26 Logic
ground
— MII MAU logic ground
27 Logic
ground
— MII MAU logic ground
28 Logic
ground
— MII MAU logic ground
29 Logic
ground
— MII MAU logic ground
30 Logic
ground
— MII MAU logic ground
DB40
Pin
Signal Direction Function
