Triconex Trident - Page 227

CM Baseplate Connectors 211
Appendix A Pin-Outs for Cables and Connectors
31 Logic
ground
— MII MAU logic ground
32 Logic
ground
— MII MAU logic ground
33 Logic
ground
— MII MAU logic ground
34 Logic
ground
— MII MAU logic ground
35 Logic
ground
— MII MAU logic ground
36 Logic
ground
— MII MAU logic ground
37 Logic
ground
— MII MAU logic ground
38 Logic
ground
— MII MAU logic ground
39 Logic
ground
— MII MAU logic ground
40 +5 V Out MII MAU power
DB40
Pin
Signal Direction Function
