3: Setting up the Edge via DMS
Views on the Edge
eg5—the eg5 model displays the total memory storage remaining in hours and minutes. For
example, if it displays the memory symbol 100:50 this represents 100 hours and 50 minutes of
memory storage remaining on the dosimeter.
Calendar symbol—the calendar symbol and calendar field displays the day-month-year.
Battery power clock symbol—the battery power clock symbol identifies the number of hours
and minutes of battery time remaining on the dosimeter.
(NOTE: Refer to page iii to view battery care and best practices.
Table 3-1: Dosimeter parameters and definitions (continued)
Edge Measurement Descriptors/Variants
The following is an explanation of the Edge descriptors and equivalents for Lmax, Lmin, and
Lcpk.
Maximum sound level—is the highest sound level recorded during a measurement interval with
a particular response setting (Slow or Fast) and weighting (A or C). Lmax is the highest value that
is included in Lavg or dose calculations.
Under OSHA regulations, unprotected workers may not be exposed to maximum sound
levels greater than 115 dB, measured with a Slow response rate.
Peak Level—is the highest instantaneous sound pressure level recorded during a measurement
interval. Unlike the maximum level, the peak is detected independently of dosimeter settings for
response rate or weighting.
Under OSHA regulations, unprotected workers may not be exposed to peak sound levels
greater than 140 dB.
Minimum sound level—the lowest sampled sound level during the measurement interval
allowing for the unit’s Response Time setting (Fast or Slow).
Table 3-2: Dosimeter measurement descriptors/variants
