3: Setting up the Edge via DMS
Auto Run Setting
Auto Run Setting
With the Edge auto-run mode, you can program up to two auto start and auto stop configurations when start
date and duration parameters are enabled. This is useful if you want to pre-set the instruments to run and
stop for a specific time period, such as a week-long study. See steps below to enable.
1. Click on the Auto-Run tab from the Edge’s Instrument Communications panel (see ❶) and click in the
Enable checkbox (see ❷).
2. To program Date 1, click in the Enabled checkbox and select a Start Date (by using the calendar icon
or type in a date). Select the Duration, by either typing in the time (designated in hours, minutes, and
seconds) or using the up/down arrows (see ❹). (Repeat this step to set up a second Auto run mode.
See ❺.)
3. To set Auto-Run setting, save and send to the Edge (for more details see “Saving and Sending
Configurations”).
Figure 3-11: Edge auto run screen
