3: Setting up the Edge via DMS
Dosimeter Setting
Setting up and Viewing C-A Measurements
With the eg5 model, you have the option of enabling C-A measurement and viewing the values
in tables and charts (also called “panels”).
For your setup parameters, C-A is selected via the Setup button of DMS’s dosimeter screen. A
quick checkmark of C minus A activates this measurement and is viewable on the display if it
is turned on in the Display screen (refer to “Noise dosimeter” or “Customizing setup
parameters in DMS” for more information.) Your setup parameters should look similar to the
figure below.
Figure 3-8: C-A measurement setup
C minus A
Activated via
checkmark
