55 Appendix A
A: Specifications
A: Specifications
*All specifications subject to change
Standards
 ANSI S1.25 Personal Noise Dosimeters
 IEC61252 Personal Sound Exposure Meters
 RoHS compliant
 Intrinsic safety:
 EN 60079-0:2013, EN 60079-11:2012, EN 60079-26:2014
 IECEx certification number: SIM 08.0012
 ATEX Directive 94/9/EC for use in Potentially Explosive Atmosphere certification
number: Sira 09ATEX2269
 CSA International (US and Canada) certificate number: 2283414
 MSHA Approval number: 18-A100008-0
Safety Markings
Manufacturer
TSI Incorporated
Equipment/model
eg5 Dosimeter
Code
Ex ia I/IIC 143ºC IP65
Ambient temp. range: -10ºC<Tamb<+50ºC
(Alternate Code)
Ex ia I/IIC T4 IP65
Ambient temp. range: -10ºC<Tamb<+40ºC
Certificate number
IECEx SIM 08.0012
Maximum charge
input voltage
Um=5.6V
Mechanical Characteristics
Housing
Plastic case with black, gray background and white outlined buttons.
Size
3.5” long x 2.1” wide x .75” thick (without microphone)
(88 mm long x 53 mm wide x 19 mm thick)
Weight
2.5 oz. (71 g), less mounting device
APPENDIX
A
