3: Setting up the Edge via DMS
Dosimeter Setting
Dosimeter Setting
The Edge general settings are used to set up the instrument with basic parameters. The eg5
model features three dosimeters in one with three customized, user-defined settings. Please
refer to the General Edge parameters table below for details. With the Edge 5, you have the
option of setting up three virtual dosimeters.
1. Click on the Dosimeter tab from the Edge’s Instrument Configuration panel (see ❶). To
change the general settings, follow one (or all) of the selection options below.
Click on the arrow and select an option.
Click on the arrows and select a numeric value or type in a value.
Click in the print settings checkbox to activate/enable the print settings feature.
2. To set the general features, save and send to the Edge (for more details see “Saving and
Sending Configurations”.
Figure 3-7: Dosimeter screen
General Edge Parameters
*NOTE: refer to Glossary for more detailed information.
When enabled (or checked), the LED will flash green while running
and flash amber when stopped.
Either Slow Time Response or Fast Time Response is applied to the
measurements. (Typically Slow time response is used in the US
market while Fast is used in the EU communities.)
When enabled (or checked), C minus A will be calculated.
Dosimeter settings
explained in the
general setup table
