Operating
Software diagnostic messages
104
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
9.2 Software diagnostic messages
The diagnostic messages of the I/O channels and the module status are displayed in plain text
both in CODESYS and in the web server.
9.2.1 Diagnostics
Diagnostics Description
Overcurrent VAUX2 pin 1 Cx (Chy - z) Overcurrent VAUX2 at pin 1 of the channel
Overcurrent output Chx Overcurrent at the respective output
Fig.100: CODESYS – I/O channel diagnostics
