Commissioning
Put master/slave functions into operation in CODESYS
42
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Which data will be mapped into the input and holding registers, depends on assignments in
the PLC program or in the I/O mapping of the TBEN-L…-PLC-….
Fig.46: Data mapping: Modbus TCPslave Device
7.3.7 Commissioning TBEN-L...-PLC-... as Modbus RTU Master
Properties
Max. number of slaves 32
Min. cycle time 5 ms
Max. number of slaves at 5 ms 8
