13 Technical data
Technical data
Power supply
Supply voltage 24 VDC
Permissible range 18…30 VDC
Total current Max. 9 A per voltage group
V1 + V2 max. 11 A
Operating current < 280 mA
Sensor/actuator supply V
AUX1
Supply of connectors C0 to C3 from V1,
C0 + C1: 2 A per connector,
C2 + C3: 4 A for both connectors
Sensor/actuator supply V
AUX2
Supply of connectors C4 to C7 from V2, 2 A per connector
Potential isolation Galvanic isolation of V1 and V2 voltage groups
Voltage proof Up to 500 VDC V1 and V2 to Ethernet
Power loss Typical ≤ 5 W
System description
Processor ARM Cortex A8, 32 bit, 800 MHz
Program and data memory 20 MB
Remanent memory 64 kB
Add-on memory 1 × USB Host port
Real Time Clock Yes
Operating system Linux
PLC data
Programming CODESYS V3
Released for CODESYS version
FW ≥ V1.3.0.0 V 3.5.12.10
FW ≥ V 1.4.6.0 V 3.5.14.20
Programming languages IEC 61131-3 (IL, LD, FBD, SFC, ST)
OPC yes
OPC UA Yes
Application tasks 10
Number of POUs 1024
Programming interface Ethernet, USB
Cycle time < 1ms for 1000 IL- commands (without I/O cycle)
Input data 8 kB
Output data 8 kB
System data
Transmission rate Ethernet 10 Mbps/100 Mbps
Connection technology 2 x M12, 4-pin, D coded
Web server default: 192.168.1.254
Service interface Ethernet via P1, P2 or Mini USB port
Modbus TCP Slave
Address assignment Static IP, BOOTP, DHCP
