7.4.6 Setup firewall for Ethernet port P2
A firewall can be set up for the Ethernet port P2 in the area Parameter Ò Firewall .
 Activate the firewall for P2 via Activate Firewall for Port 2.
 Define Fix Firewall rules or define own firewall rules under User firewall rules x.
 Write the changes into the device via the Write.
 Apply firewall rules via the Apply button.
Fig.92: Web server – setting up the firewall
NOTE
If the firewall on port 2 is activated and the TBEN-L...-PLC-... is to be connected to the
Turck Cloud via port 2, the firewall rule Turck Cloud (port 443) must be deactivated.
