8.1.2 Parameters of the local DXP channels (Local I/O)
Default values are shown in bold.
Parameter name Value Description
Activate output No The output is deactivated.
yes
The output is activated.
Manual output reset after
overcurrent
No
The output switches on automatically after an
overload.
yes The output is manually switched-off and on
again.
8.1.3 Parameter VAUX Control
Parameter VAUX Control (for sensor/actuator supply)
Default values are shown in bold.
Parameter name Value Description
VAUX2 Pin 1 Cx (Chy - z)
24 VDC
The 24 VDC sensor/actuator supply at Pin1 of
the connector is switched on.
switchable The 24 VDC sensor/actuator supply at pin1 of
the respective connector is switchable via the
process data.
off The 24 VDC sensor/actuator supply at Pin1 of
the connector is switched off.
8.1.4 Interface parameters – COM0/COM1
The parameters can only be set in CODESYS.
Default values are shown in bold.
Parameter name Value Description
Data rate
9600 bps
Data rate of the serial interface
19.2 kbps
38.4 kbps
57.6 kbps
115.2 kbps
230.4 kbps
Data bits 7 bit Defines the number of data bits per telegram
8 bit
Stopp bits
1 bit
Defines the number of stop bits
2 bit
Termination active
No
No line termination active
yes Line termination activated (only valid for oper-
ation mode RS485)
Biasing active
No
Deactivates the biasing resistor
yes Activates the biasing resistor
Voltage supply VAUX1
off
VAUX1 is switched off
V1 (24 VDC) VAUX1 from V1 (24 VDC) is switched on
