Configuring and Parameterizing
Parameters
92
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Parameter name Value Description
IP Forwarding
deactivate
The forwarding of IP packets between the two
Ethernet networks (on port 1 and port 2) is not
possible.
activate The forwarding of IP packets between the two
Ethernet networks (on port 1 and port 2) is ac-
tivated.
Device name Device name to be assigned to the PROFINET
device.
Ethernet port 1/2
Connection mode
Auto negotiation
Sets the Ethernet port to Auto-negotiation or
to a fixed value for transmission rate and trans-
mission mode.
10 Mbps, half duplex
10 Mbps, full duplex
100 Mbps, half duplex
100 Mbps, full duplex
IP address Default setting:
Port1:
192.168.1.254
Port 2:
192.168.2.254
Network settings for the relevant Ethernet port
on the device.
If the device is operated in switch mode, only
the setting for port 1 can be made here. In
Dual MAC mode, the Ethernet ports are set in-
dependently of each other.
Net mask Default setting:
255.255.255.0
Default gateway Default setting:
Port1:
192.168.1.1
Port 2:
192.168.2.1
Firewall (can only be
set via web server)
Activate firewall for
port2
No
No firewall activated for port 2
yes Activates the firewall for Ethernet port P2 in
the Dual MAC mode.
Fix firewall rules The firewall rules for port 2 can be customized
to meet application requirements.
To apply the firewall rules, you must first activ-
ate the firewall itself using the Firewall for
Port 2 parameter.
If the firewall is activated, proceed as follows:
 Define fixed or user firewall rules.
 Write firewall rules to the device using
the Write button.
 Apply firewall rules via the Apply but-
ton.
User firewall rules
1…16
