Commissioning
Put master/slave functions into operation in CODESYS
50
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
7.3.10 Commissioning TBEN-L...-PLC-... as PROFINET Device
Configuring the PROFINET Device
NOTE
In Dual MAC mode, the PROFINET Device function is only available on Ethernet port
P1 (eth0 in CODESYS).
ü The Ethernet interface eth0 is configured.
ü The Profinet_Device from Turck is used.
 Add the Profinet_Device to Ethernet using the Add Device function.
 Configure the in- and output data lengths which have to be exchanged with the higher-
level PROFINET Master.
Fig.54: Configuring the PROFINET Device
