turck TBEN-L Series Instructions For Use

V02.00 | 2019/11
123
Technical data
Supported function codes FC1, FC2, FC3, FC4, FC5, FC6, FC15, FC16, FC23
Input registers Max. 1024 registers
Input register start address 0x0000
Holding Registers Max. 1024 registers
Output register start address 0x0000
Modbus RTU Slave
Input registers Max. 500 registers
Input register start address 0x0000
Holding Registers Max. 500 registers
Output register start address 0x0000
EtherNet/IP™ Device
Address assignment according to EtherNet/IP™ standard
Number of process data Max. 248 words input data, max 246 word output data
PROFINET Device
Address assignment DCP
Conformance Class B (RT)
MinCycle Time 1 ms
Diagnostics according to PROFINET Alarm Handling
Automatic address setting Supported
Topology detection Supported
Number of process data n Up to firmware version V1.2.1.0: max. 512 byte input
data/max. 512 byte output data
n From firmware version V1.3.0.0: max. 1024 byte input
data/max. 1024 byte output data
CAN Device
Baud rate Up to 1 Mbps
Power supply Internal from V1 (no external power supply allowed)
Number of PDOs Max. 512 RxPDOs max. 512 TxPDOs
Modbus TCP Master
Max. number of devices 64
Min. cycle time 2 ms
Max. number of devices at 2 ms 8
EtherNet/IP™ Scanner
Input data max. 8 kB
Output data max. 8 kB
Max. number of devices at 10 ms 8
PROFINET Controller
Max. number of devices 64
Min. cycle time 1 ms
Max. number of devices at 1 ms 8
Modbus RTU Master
Max. number of devices 32
Min. cycle time 5 ms
