Technical data
Max. number of devices at 5 ms 8
CANopen Manager
Input data max. 8 kB
Output data max. 8 kB
Max. number of devices 127
SAE J1939 Manager
Input data max. 8 kB
Output data max. 8 kB
Max. number of devices 254
Digital inputs
Number of channels 8
Connection technology M12, 5-pole
Input type PNP
Type of input diagnostics Short-circuit diagnostic of sensor supply per connector
Switching threshold EN 61131-2 type 3, PNP
Signal voltage, low level < 5 V
Signal voltage, high level > 11 V
Low level signal current <1,5 mA
High level signal current > 2 mA
Sensor supply 2 A, short-circuit proof, from V2,
optionally switchable via process data
Potential isolation Galvanic isolation to P1/P2
Voltage proof Up to 500 VDC (V1 and V2 to Ethernet)
Digital outputs
Number of channels 8
Connection technology outputs M12, 5-pole, a-coded
Output type PNP
Type of output diagnostics Short-circuit diagnostic per channel
Output voltage 24 VDC from V2
Output current per channel 2 A, short-circuit proof, max. 4.0 A per connector
Simultaneity factor 0.56
Load type Ohmic, inductive lamp load
Short-circuit protection Yes
Actuator supply 2 A, short-circuit proof, from V2, optionally switchable via
process data
Potential isolation Galvanic isolation to P1/P2
Voltage proof Up to 500 VDC (V1 and V2 to Ethernet)
Standard/Directive conformity
Vibration test According to EN 61131
Shock test According to EN 60068-2-27
Drop and topple According to IEC 60068-2-31/IEC 60068-2-32
Electro-magnetic compatibility According to EN 61131-2
Approvals and certificates CE, FCC
