Addressing options
The IP address of the devices can be set in different ways. The following addressing options can
be selected via the switches on the device. Changes to the settings become active after a
voltage reset.
Setting option DIP switch “MODE” Rotary coding
switches
Description
Rotary mode 0 1…99 In rotary mode, the last byte of the IP address can be
set manually at the gateway. The other network set-
tings are stored in the non-volatile memory of the
gateway and cannot be changed in rotary mode. Ad-
dresses from 1...99 can be set.
0 00 IP address: 192.168.1.100
Subnet mask: 255.255.255.0
Gateway: 192.168.1.1
DHCP mode 1 40 In DHCP mode, the IP address is automatically as-
signed by a DHCP server in the network. The subnet
mask assigned by the DHCP server and the default
gateway address are stored non-volatile in the
memory of the gateway DHCP supports three mech-
anisms for IP address allocation:
n Automatic address assignment: The DHCP server
assigns a permanent IP address to the client.
n Dynamic address assignment: The IP address as-
signed by the server is only reserved for a certain
period of time. After this time has elapsed or after
the explicit release by a client, the IP address is re-
assigned.
n Manual address assignment: A network adminis-
trator assigns an IP address to the client. In this
case, DHCP is only used to transmit the assigned
IP address to the client.
n Default IP address: 192.168.1.254
PGM Mode 1 50 In PGM mode, the complete IP address is assigned
manually via the Turck Service Tool, FDT/DTM or via
a web server. In PGM mode, the set IP address and
the subnet mask are stored in the memory of the
gateway. All network settings (IP address, subnet
mask, default gateway) are taken from the internal
EEPROM of the module.
n Default IP address: 192.168.1.254
PGM DHCP mode 1 60 In PGM-DHCP mode, the gateway sends DHCP re-
quests until it is assigned a fixed IP address. The
DHCP client is automatically deactivated if an IP ad-
dress is assigned to the gateway via the DTM or a
web server.
n Default IP address: 192.168.1.254
F_Reset 1 90 The F_Reset mode sets all device-settings back to the
default values and deletes all data in the device's in-
ternal flash. The following values are reset or deleted:
n IP address: 192.168.1.254
n Parameters
Restore 1 00 Enter the device name and the device's IP address.
