Cooling System (Radiator) (ref. Fig. 26)
A coolant is used in the motorcycle cools the hot
engine and ensures that operating the vehicle at
specified temperature which in-turn avoids the risk of
malfunctions.
• A radiator and cooling fan fitted in the cooling
system does job of cooling the coolant used in
the motorcycle by air stream.
• Dirty cooling foils of radiator reduces the cooling
effect. Do the visual check and ensure the cooling
foils of the radiator are not clogged with any
dirt or mud. If so contact TVS Motor Company
Authorised Main Dealer.
• A coolant reservoir tank (A) is fitted on the right
side of the motorcycle below the side panels
(ref. Fig. 27).
• Visually inspect the coolant level in the tank (use
a torch if required).
The cooling fan may switch ‘ON’ approx 22 secs. after
the ignition is turned ‘OFF’ to reduce the heat and to
protect the engine which is normal. Need not panic.
Note
Fig. 26
A
Fig. 27
