Gear Shift Pedal (ref. Fig. 16)
This motorcycle is equipped with a 6 speed constant
mesh transmission.
• To select the required gear or to bring the vehicle
to neutral, a gear shift lever (A) is provided and it
is located on the LH side of the vehicle.
• To engage the 1st gear or to down shift the gear
press the pedal down.
• To engage 2nd, 3rd, 4th, 5th and 6th gear or to
upshift the gear, lift the pedal upwards.
- Each time you move the pedal you will be
engaging the next gear.
- Gear shift pedal returns to its position (centre
position) automatically when released after
shifting.
- Once the transmission is brought to neutral
position, the neutral indicator ‘ ’ of the
instrument cluster illuminates.
Apply the clutch when starting the vehicle with gear
engaged.
Gear shift pedal position can be adjusted as per the
convenience of the rider. Refer page 142 for adjusting
procedure.
A
1
N
2
3
6
5
4
Fig. 16
