Type Three phase AC generator
Ignition system Dynamically controlled - high energy integrated ignition system
Spark plug NGK (LMAR9D - J)
Spark plug gap 0.8 ± 0.1 mm
Battery type 12V / 8 Ah MF wet charge type
Body earthing
Two grounds are mounted on engine body (1. Engine ground
and 2. Ignition ground) and one ground mounted on fuel tank
Generator 12V, 290W
Headlamp 12V, LED (46W)
DRL lamp 12V, LED (9W)
Tail / brake lamp 12V, LED (1W / 3W approx.)
Turn signal lamp 12V, LED (4W each)
Number plate lamp 12V, LED (1.5W)
Instrument panel TFT / LED indicators
Horn type 12V DC two numbers
Fuse Mini fuse - 7.5A x 2, 10A x 2, 15A x 2 and 30A x 1
Voltage regulator Three phase shunt full DC RR unit
Electricals
