Seat Lock (Rider and Pillion Seat)
This motorcycle is equipped with a lockable rider and
pillion seats. The seat lock (A) is located between the
rider and pillion seat as shown (ref. Fig. 34)
To open the pillion seat:
• Insert the control key into the seat lock. Rotate
the key in clockwise until the lock is released.
• First, slide the seat towards vehicle front
direction.
• Ensure the hook underneath got released from
frame and take out the seat.
A
Fig. 34
• Inspect the shock absorber for any dirt or mud
accumulation on it or any fluid leak.
- If found any, clean them properly using a soft
cloth and brush.
- If any oil leak is found contact TVS Motor
Company Authorised Main Dealer.
During time of delivery of the motorcycle, the rear shock
absorber is adjusted to the standard configuration.
Note
