Engine Oil Level
Ensure the safety precautions listed in the page
160 are followed properly.
Check the engine oil level before riding the motorcycle.
Insufficient engine oil or too much engine oil affects
the engine adversely.
To check the engine oil level, a gauge oil level (dip
stick) (A) given on the left side of the crankcase
(ref. Fig. 50).
• Wipe off the surroundings of the gauge oil level.
Start the engine and let it idle for 3 to 5 minutes.
• Switch ‘OFF’ of the ignition. Hold the vehicle
in upright condition with both the wheels on
ground, on a flat and firm surface.
• After 2 to 3 minutes, remove the gauge oil level
(A) and wipe it cleanly.
• Re-fix the gauge again. Slowly and steadily
remove the gauge and inspect the oil level.
• The level should be between minimum (1) and
maximum level (2) mark on the gauge (ref.
Fig. 51).
• If the level is below the minimum level (1), slowly
add recommended engine oil till the level reaches
to maximum level (2).
1
2
A
Fig. 50
Fig. 51
