174
Front Wheel
Ensure the safety precautions listed in the page
160 are followed properly.
Removal
• Carefully place the motorcycle in auxiliary stand
(paddock stand refer page 192).
• Loosen the right side clamping screws (1) and (2)
(ref. Fig. 65).
• Remove the locking screw (3) (ref. Fig. 66).
• Loosen the left side clamping screws (4) and (5)
(ref. Fig. 66).
• Slightly press the quick-release axle (8) inward for
a better grip on the right side (ref. Fig. 67).
8
1
2
Fig. 65
Fig. 67
6
4
5
7
3
Fig. 66
