Location of Parts - Vehicle LH Side View (Ref. Fig. 02)
1. Disc plate front
2. Caliper assembly front
3. Gauge oil level (dipstick)
(ref. page 161)
4. Gear shift pedal
(ref. page 34)
5. Side stand
6. Rear shock absorber
(ref. page 126)
7. Rider foot rest LH
8. Pillion foot rest assembly LH
9. Pillion seat
10. Rider seat
1
2
5
3
4
6 8
10 9
Fig. 02
7
