Ignition cum Steering Lock
Ignition cum steering lock is located on the top of fuel
tank at front end and has following three positions
(ref. Fig. 09):
• OFF (A): Disables lights and engine operation.
• ON (B): Enables lights and engine operation (with
engine cut off switch is in run mode ‘ ’).
• LOCK (C): Steering is locked
- To lock the steering, turn the handle bar all the
way towards left or right, push the key in and
turn it to ‘LOCK’ position. Push and turn the
key to ‘OFF’ or ‘ON’ position to unlock.
Control key can’t be taken out from the lock at position
(B).
The tail lamp and license plate lamp will glow
automatically when the ignition is turned ‘ON’ without
operating any other switches. Headlamp / DRL works
based on their settings (OFF / Automatic) and the input
from the ambient light sensor of the instrument cluster.
The instrument cluster performs pre-check once the
ignition lock is turned ‘ON’. Wait till the completion of
pre-check.
Note
On level ground, always turn the handle bar towards
left while locking the steering when the vehicle is
propped with side stand. Else the vehicle may fall and
may get damaged. Otherwise the angle of the ground
determines the steering position (left or right).
Always lock the steering while parking for safety.
Ensure that, you do not keep the ignition ‘ON’ without
starting the engine for a long time as battery might get
drained because of AHO and DRL.
P
U
S
H
B
A
C
Fig. 09
