43
43
Symbol Lights Meaning
A. Photo sensor cum shift light
indicator
Alters the headlamp high beam based on the vehicle speed to provide better
visibility even at high speed when the headlamp is in automatic mode.
Turns ‘ON / OFF’ the Day Running Light (DRL) as per day and night conditions.
Adjust the TFT brightness and tell tale indicators brightness automatically as
per day and night conditions.
Shift indicator also indicates the over speed limiter and upshift / downshift
indication of gear.
B. Turn signal indicator RH Flashes when the right side turn signal indication is activated.
C. EMS malfunction indicator
Glows when any problem is detected in the engine management system
causing vehicle to exceed on-board diagnostic emission threshold.*
D. High beam indicator Glows when the headlamp high beam is activated.
E. ABS malfunction indicator
Flashes when the ABS self-diagnostic not completed / not yet initiated - Ride
the vehicle few kms.
Glows continuously when the ABS has an error or malfunction.*
Goes OFF after few kms run - ABS is active and ready to use.
Warning and indicator lights (ref. Fig. 22)
* Contact TVS Motor Company Authorised Main Dealer
