Fuel Tank Cap (ref. Fig. 29)
This motorcycle is equipped with a lockable fuel tank
cap (A).
To open:
• Lift the protection lid (A).
• Insert the control key into the lock. Rotate the key
a 1/4 turn clockwise and lift the cap (B).
B
To close:
• Push the cap down into its seat until hearing a
click sound.
• Turn the key anticlockwise to the initial position
and remove it.
• Close the protection lid.
Refueling (ref. Fig. 30)
Never overfill the tank when refueling. The fuel level
always be below the brim of the fuel tank neck (A).
FUEL
A
A
* The fuel tank is not a measuring instrument and the
capacity of the fuel tank may slightly vary from the
indicated capacity.
Fig. 29
Fig. 30
