148
Rebound damping**
The shock absorber is provided with rebound
damping force adjustment.
• To increase the damping turn the adjuster screw
clockwise and to reduce the damping turn the
adjuster screw in anti-clockwise direction as
shown figure (ref. Fig. 47).
- During adjustment count the numbers of
clicks from fully closed (clockwise) position.
Fig. 47
** Applicable for specific Apache RTR 310 BTO versions only
