164
Clutch play free play should be checked and adjusted
only when the engine is cold.
During clutch play checking and adjustment, check the
clutch cable for kinks or sign of wear that could cause
stickiness or failure.
Lubricate the clutch cable using a cable lubricant available
in the market to prevent premature failure and corrosion.
• Lock the lock nut (3) again.
- If the adjuster is threaded out to its maximum
limit or if the correct free play cannot be
obtained using the cable adjuster, loosen the
lock nut and completely turn-in the clutch
cable adjuster.
• Re-fix the dust cover (2) and cable clamp (1).
• Loosen the lock nut (5) at the bottom end of the
clutch cable (ref. Fig. 54).
• Turn the adjuster in (6) ‘in’ or ‘out’ until the
specified play is obtained and then tighten the
lock nut and check the adjustment once again
(ref. Fig. 54).
- After adjusting the clutch play, start the
engine and engage the gear. Ensure that the
engine is not stalling and not creeping.
- Gradually release the clutch lever while slowly
applying the throttle. The vehicle should begin
to move slowly and accelerate smoothly. Else
contact TVS Motor Company Authorised
Main Dealer.
6
5
Fig. 54
