3a
Fig. 86
Fig. 87
• Apply uniform pressure to push the stand down
and raise the motorcycle (ref. Fig. 87).
• Tighten the clamping screws (1) (ref. Fig. 84).
Rear wheel stand
Use the rear wheel stand (the rear wheel stand is
an accessory and it is available with the TVS Motor
Company Authorised Main Dealer).
• Ensure that the motorcycle is parked on a flat and
firm surface.
• Loosen the clamping screws (1) of the stand
adopters.
• Move away the adopters (2 & 3) in such way that
the swing arm fits between them (ref. Fig. 88).
• Ensure that the axle is not covered.
1
2
3
1
Fig. 88
To Next Page
