54
a1.4. Fuel level indicator
• Digital bars (a1.4) indicates the approximate
quantity of fuel available in the tank.
- There are eight bars to indicate the quantity
fuel.
- If the fuel level is less than 2.2 liters, the low
fuel indicator of the instrument cluster ‘ ’
starts glowing.
- If the fuel level reaches to minimum safe level
ie. lesser than 2 liter approximately, fuel level
indicator displays a single bar.
- Fill fuel (refer page 123) immediately.
- All the eight bars will be displayed when the
fuel level in the tank reaches approximately
11 liters.
- When the fuel level reduces to 5 liters
(approx.) the indicator displays only five bars.
Please ensure that the fuel bar indication in the cluster
is greater than 1 bar always. It is unsafe to ride with
1 bar or less.
Incase of any error in input system, all the bars of fuel
level indicator flashes and low fuel warning indicator
turns ‘ON’. Contact nearest TVS Motor Company
Authorised Main Dealer incase any of these problems
are noticed.
km/h
5
60
1
2
0
45 6781091112
r
p
m
x
1
0
0
0
AVG. MILEAGE
31.3
km/l
ODO
8
km
03.17
s
0 - 60 km/h A
KILL SWITCH
KILL SWITCH
SIDE STANDSIDE STAND
LOW FUELLOW FUEL
LOW BATTERY
LOW BATTERY
TYRE PRESSURE
40 39
a1.4
