MODEL T723
Final reduction gears
Type Helical gears
Reduction ratio 4.9
Brake system
Friction
Plate
Type Wet, multi-disc, Mechanically operated
diameter Φ140(Φ5.5in)xΦ180mm(Φ7.0 in)
Thickness 3.4±0.1 mm(0.134 in)
Lining material Paper base
Number of plates 5 on each side
Separator
Plate
Outer diameter Φ188mm(Φ7.4 in)
Thickness 2.5±0.09 mm(0.098 in)
Number of plates 5 on each side
Metal brake assembly
Installed thickness
36 ±0.1 mm(1.417 in)
Total brake thickness 66.4(2.614in.)
SECTION 2. SPECIFICATIONS
