Type Spring Center Floating Detent
Maximum flow (ℓ/min) 45 LPM 45 LPM
Maximum pressure (kgf/㎠) 210 210
A and B port leak
Oil temperature:50℃(122℉)
Under a load of 100 kgf/㎠
9 cc/min below 20 cc/min below
Recommended fluid THF 500 THF 500
Operating temperature range -20℃~80℃ -20℃~80℃
3. SPECIFICATIONS
9-35
3.1 HYDRAULIC CIRCUIT
Fig. 9-69 Remote hydraulic pump
P:From pump T: To tank A, B : High pressure port, Return port
Floating Detent
Spring Center
