TYM T723 User Manual

11-6
Part names and
inspection items
Nominal
dimensions
Standard value
for reassembly
Usable limits Service instructions
and remarks
5.REAR AXLE (CHAPTER 7)
1) DISK BRAKE
FRICTION
PLATE
THICKNESS
(WEAR AND
CARBONIZER )
3.4 ± 0.15 ㎜ 3.2 ㎜
2) SEPARATE PLATE
Thickness
(wear and
damage)
2.5 ± 0.05 ㎜ 2.4 ㎜
3) BRAKE ROD TURN BUCKLE
Pedal play at the
top
30 ∼40 ㎜
6. POWER STEERING SYSTEM( CHAPTER 8)
1) GEAR PUMP
Capacity 7.2 sec/rev
Direction of
revolution
CCW as viewed from the shaft of the gear pump
7.HYDRAULIC SYSTEM (CHAPTER 9)
1) PISTON AND CYLINDER
cylinder and bore Ø100 ㎜
0-ring : Inner Ø100㎜
