TYM T723 User Manual

11-5
Part names and
inspection items
Nominal
dimensions
Standard value
for reassembly
Usable limits Service instructions
and remarks
4. FRONT AXLE (CHAPTER 6)
1) Front drive axle (4WD)
Tire inflation Front : 2.4 ㎏f/㎠
Rear : 1.6 ㎏f/㎠
Wheel alignment ①Toe-in : 0 ~5 ㎜
②Camber : 2°
③Caster : 2°
④King-pin : 15 °
⑤Steering angle: (RH : 52 °) (LH: 52°)
Front
center
pivot
shaft.dia. 50 × 55 × 40 Ø 55 ㎜ Ø 54.9 ㎜ wear limit : 0.1 ㎜
bush 50 × 55 × 35 Ø 50 ㎜ Ø 50.2 ㎜ wear limit : 0.2 ㎜
Rear
center
pivot
shaft.dia. 100 ×106.3 ×35 Ø 100 ㎜ Ø 99.9 ㎜ wear limit : 0.1 ㎜
bush 100 ×106.3 ×30 Ø 100 ㎜ Ø 100.2 ㎜ wear limit : 0.2 ㎜
Play in bush 0.3 ㎜
Thrust play 0.1 ∼ 0.4 ㎜ 0.5 ㎜ Adjust with adjusting
shims
DIFF
ERE
NTIA
L
Pinion
gear
9 ∼11㎏f·cm
Starting
torque
11~13 ㎏f-cm
Thrust play 0.13 ∼ 0.2 ㎜ shim: 0.1, 0.2 ㎜
Drive pinion/ring
gear backlash
0.1 ∼ 0.2 ㎜ shim: 0.1, 0.2 ㎜
