TYM T723 User Manual

SECTION 2.SPECIFICATIONS
NOTE: Recommendable Transmission oil
Manufacturer :Product
CALTEX :Textran TDH Premium
Texaco :TDH oil
Chevron :Chevron 1000THF
ESSO :Torque Fluid 56
MOBIL :Mobil fluid 423
SHELL :Donax TD
CASTROL :CASTROL AGRI MULTITRANS
TOTAL :Transmission MP
9-3
MODEL T723
Piston and cylinder Hitch lift capacity, lb.(kg) 4,330 (1,964)
Control valve Cylinder port leaks (under a
pressure of 9800KPa[(100Kgf/㎠)
with gear oil of SAE 80)]
5cc(0.305 Cu in)
Main relief valve Max. pressure 200 Kgf/㎠
Relief pressure 170 +5 Kgf/㎠
Gear Pump Front Rear
Delivery(90% efficiency) :
liter(cu.in)mm at 2200rpm
16 ㎤/rev
(36 ℓ /min)
7.2 ㎤/rev
(16 ℓ /min)
Cracking pressure 145 125
Working pressure(kgf/cm
2
) 170 +5 140
Suction filter Rated flow: (ℓ /min) 43
Filtration density 150 mesh
Filtration area 6,231 ㎠
Connector 1 ¼ - 12 UNF
Line filter
(Reference)
Rated flow: (ℓ /min) 35
Filtration density 100 mesh
