TYM T723 - Section 2. Specifications; Gear Pump; Oil Tank

SECTION 2. SPECIFICATIONS
1) GEAR PUMP (Power Steering)
MODEL T723
Delivery (cc/rev) 7.2
Displacement (ℓ/min)
(2200rpm x 34/73*73/33*23/19)
17.7
( at 90% )
Pump performance
At 150
(kgf/cm
2
)
1000 rpm 6.2 LPM
1800 rpm 11.9 LPM
2600 rpm 17.5 LPM
Maximum pressure (kgf/㎠) 210 kgf/㎠
Rated operation speed (rpm) 500~3000 rpm
Rotation direction C.C.W as viewed from shaft end
2) Power steering valve Unit
MODEL T723
Model number UVS140C16LJD
Displacement (cc/rev) 80
Rated flow (ℓ/min) 16
Maximum system pressure (kgf/㎠) 175 (17 Mpa)
Max. back pressure (kgf/㎠) 35 (3.4 MPa)
Max. temperature(℃) 95
Input torque (N.m) 1.2 (0.1 kgf.m) (SAE10T-16/32)
Main relief pressure setting (kgf/㎠) 150 kgf/㎠ (at 16ℓ/min)
Weight (kgf) 5.5 (12.12lb)
3) OIL TANK
MODEL T723
TANK Transmission Case
Fluid volume (ℓ) 43ℓ (11.36 gal)
Fluid THF500
8-2
