2) PTO DRIVE SYSTEM
MODEL T723
Speed shift range 2
Reduction ratios. 1 Step : 1 / 4
2 Step : 1 / 3
PTO shaft speeds 550, 733 @ 2200
PTO shaft size Ø35mm(1 3/8 in) 6-splines
Rotational direction Clockwise viewed from the rear
PTO
clutch
Wet, multi-disc, hydraulic-operated clutch
No.of clutch plates Friction plate : 7, Clutch plate : 6
Oil used THF500
Model T723
Speed shift range forward
reverse
24
24
Reduction
ratios.
Reverse shift
forward
reverse
1/ 1.304
1/ 1.273
Creep shift
Creep off
Creep on
1/1
1/3.322
Main speed shift
1st
2nd
3rd
4th
1/ 2.111
1/ 1.333
1/ 0.866
1/ 0.697
Speed range shift
(Sub-speed shift)
L
M
H
1/ 10.478
1/ 3.280
1
Drive pinion-Ring gear 1/ 4.364
Final reduction
1/ 4.909
Operation
methods
Reverse shift
Column shift
Main speed shift Side shift (RH)
Speed range shift Side shift (LH)
Oil capacity
Transmission case 43ℓ (11.36 US gal)
SECTION 2. SPECIFICATIONS
1. WHEEL DRIVE SYSTEM
5-8
